Quick Detail:
Our company short non woven fiber geotextile is soft, thick, plump and stiff, and suitable for different thickness. It is a new special geotechnical engineering construction material made from polypropylene PP, and polyester PET. Short non woven fiber filament geotextile is interweaved by advanced equipment and special steps with different kinds of fibers by needling punch and other procedures and are laid into nets
When the yarn is long, it can make non woven filament fibers, when yarn is short, it can make short non woven filament fibers.
Wanshengli brand short fiber non woven geotextile is made from PP polypropylene, and PET polyester, which is a new special geotechnical engineering construction material. Short non woven fiber filament geotextile is interweaved into net by high technology, advanced equipment and special steps with different kinds of fibers by needling punch and other procedures.It is ok for different thickness, because short filament fabric is stiff, thick, plump and soft.
Product Features
No. |
Item Index Specification |
100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 | Remarks |
1 | Unit area mass deviation,% | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | -6 | -6 | |
2 | thickness, mm ≥ | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3 | 3.3 | 3.6 | 4.1 | 5 | |
3 | Width deviation, % | -0.5 | |||||||||||
4 | Breaking strength, KN/M ≥ | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.6 | Vertical and horizontal |
5 | Elongation at break, % | 25-100 | |||||||||||
6 | CBR bursting strength,KN ≥ | 0.3 | 0.6 | 0.9 | 1.2 | 1.5 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4 | |
7 | Equivalent aperture,O99(O35),mm | 0.07-0.2 | |||||||||||
8 | Vertical permeability coefficient,cm/s | KX(10 -1 -10 -3 ) | K=1.0-9.9 | ||||||||||
9 | Tear strength 3,KN ≥ | 0.08 | 0.12 | 0.16 | 0.2 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.4 | 0.6 | Vertical and horizontal |
Geosynthetic fabric has widly used in our domestic civil engineerig fiel,it's a new engineering construction material.
Applications
Short Fiber Geotextile Package
Product packed as rolls with tight belt and woven bags. It can gurantee convenient unloading and protecting product.
All products will be deliveried on time according to our customer's requirements.
All products will be delivered in time according to the requirement
