PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations

1200 sqm
MOQ
USD 0.25 ~ USD 3.80 per square meter or can be negotiated.
Price
PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations
Features Gallery Product Description Request A Quote
Features
Specifications
Colour: White&black
White Black: PE
Can Be Applied To: Asphalt Pavement, Sewage Treatment Plants, Coastal Beaches, Roads, Railways, Etc
Length: 50m 100m
Width: 5.8m
MOQ: 1200 Sqm
High Light:

300gsm Nonwoven Geosynthetic Fabric

,

300gsm PP Geosynthetic Fabric

,

300gsm PP nonwoven geotextile

Basic Infomation
Place of Origin: Anhui Luan China
Brand Name: wanshengli
Certification: ISO9001, ISO14001,OSHSAS18001,GM-13, ASTM
Model Number: 300gsm
Payment & Shipping Terms
Packaging Details: Woven Plastic Bag packing
Delivery Time: Normally within 15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram or through alibaba trade assur
Supply Ability: 40000 sqm per day
Product Description
For mines, road foundations, etc., the use of this geosynthetic fabric will play a role in protecting against seepage.


Quick Detail:

Material: polyethelene, PE

Function: Protect, isolation
Width: 5.8m
Application: underground project



Wanshengli brand short fiber non woven filament geotextile is made from PP polypropylene, and PET polyester, which is a new special geotechnical engineering construction material. It is ok for different thickness, because short filament fabric is stiff, thick, plump and soft. Short non woven fiber filament geotextile is interweaved into net by high technology, advanced equipment and special steps with different kinds of fibers by needling punch and other procedures.



Because of the difference yarn, it has 2 types:



1. short non woven filament geotextile

2. non woven filament fiber geotextile



The short non-woven geotextile filament fiber has resistance of high temperature up to 230℃ to guanrantee maintain structure stability, high flat drainage, high elongation under certain stress, high creep resistance and vertical permeability, so can be applied in uneven and irregular bases. Many geotechnical engineering projects can use short non-woven geotextile filament fiber as materials.



Geosynthetic Fabric Features

  • Filtration
  • Erosion & sediment control
  • Sub-grade stabilization
  • Protection for geomembrane liners
  • Shoreline protection
  • Drainage




PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 0

Product Parameter

No.

Item

Index

Specification

100 150 200 250 300 350 400 450 500 600 800 Remarks
1 Unit area mass deviation,% -8 -8 -8 -8 -7 -7 -7 -7 -6 -6 -6
2 thickness, mm ≥ 0.9 1.3 1.7 2.1 2.4 2.7 3 3.3 3.6 4.1 5
3 Width deviation, % -0.5
4 Breaking strength, KN/M ≥ 0.08 0.12 0.16 0.2 0.24 0.28 0.33 0.38 0.42 0.46 0.6 Vertical and horizontal
5 Elongation at break, % 25-100
6 CBR bursting strength,KN ≥ 0.3 0.6 0.9 1.2 1.5 1.8 2.1 2.4 2.7 3.2 4
7 Equivalent aperture,O99(O35),mm 0.07-0.2
8 Vertical permeability coefficient,cm/s KX(10 -1 -10 -3 ) K=1.0-9.9
9 Tear strength 3,KN ≥ 0.08 0.12 0.16 0.2 0.24 0.28 0.33 0.38 0.42 0.4 0.6 Vertical and horizontal



Geosynthetic fabric is a new engineering construction material as standardized product it has widly used in our domestic civil engineerig field.



Applications

  • As the isolation layer and for inverted layer dam, slope protection, road, railway, airfield runway.
  • Reinforcement and drainage for soil slope,retaining wall.
  • Reinforcement and drainage for Asphalt pavement, cement concrete pavement and subgrade enhancement. Both rigid and flexible road pavement applicable.
  • Soft foundation treatment/ soft soil improvement of port project; the reinforcement and drainage for beach dike, seaport wharf and seawall/bulwark.

PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 1

PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 2



Geosynthetic Fabric Geotextile Package



packed as rolls with tight belt and woven bags. It can gurantee convenient unloading and protecting product.



PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 3

PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 4

PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 5

PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 6PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 7PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 8PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 9PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 10PP Geosynthetic Fabric Nonwoven Geotextile Road Foundations 11
