ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill

Basic Information
Place of Origin: Luan Anhui China
Brand Name: Wanshengli
Certification: ISO9001, ISO14001,OSHSAS18001,GM-13, ASTM
Minimum Order Quantity: 1000sqm
Price: 1.4 USD ~3.8 USD per sqm
Packaging Details: Woven Plastic Bag
Delivery Time: 5~8 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 50000 sqm per day
Detail Information
Material: Bentonite Clay Color: Black And White
Certificate: ISO9001 MOQ: 1000sqm
Packing: Standard Packing Payment: T/T
OEM: Support Sample: Provided
High Light:

ASTM Geosynthetic Clay Liner

,

Landfill Geosynthetic Clay Liner

,

Landfill geosynthetic liners


Product Description



Good Earthwork Products Waterproof Bentonite Clay Blanket With Cheap Price





GCL Bentonite Waterproof Blanket

GCL Waterproof blanket is combined with 3 parts. The upper level and the lower level are woven geotextile and non woven textile, the middle level is bentonite clay, which are carefully selected crude and filled in between the two levels after special processing. The bentonite clay in GCL made by this method does not flow in a fixed direction. It distributes evenly and forms waterproof layer, owning excellent waterproof features. This GCL is a kind of new green waterproof materials, which are widely applied in many waterproof construction projects.





ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 0



ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 1

Product Parameter

Item Technical Index
GCL-NP GCL-OF GCL-AH
Bentonite Weight(g/m2) ≧4000 ≧4000 ≧4000
Bentonite Swelling index(mL/2g) ≧24
Methylene blue index(g/100g) ≧30
Tensile Strength( N/100mm) ≧600 ≧700 ≧600
Elongation Under Maximum Load(%) ≧10 ≧10 ≧8
Filter Loss(ml) ≦18 ≦18 ≦18
Bentonite Durability(ml/2g) ≧20 ≧20 ≧20
Hydrostatic Pressure Resistence 0.4MPa,1h 0.6MPa,1h 0.6MPa,1h
Coefficient Permeability(m/s) ≦5.0x10-11 ≦5.0x10-12 ≦1.0x10-12



ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 2

ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 3ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 4ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 5ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 6ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 7ASTM Waterproof Bentonite Geosynthetic Clay Liner Blanket For Landfill 8
