Quick Detail:
Material: polyethelene, polyester
Weight: 110g 120g 150g 200g
Ecological bag is a kind of high strength anti-uv anti-freezing and thawing anti-acid and alkali ecological synthetic material, is a new high-tech special material, with high strength anti-uv anti-acid and alkali anti-corrosion anti-freezing and thawing can reach more than 50 years of non-degradation, it is resistant to moisture, does not absorb water, does not damage the bag, does not deform, and is insoluble in polluted liquid.
Geobag (Ecological protection bag) is made of double-sided ironing needle punched non-woven fabrics made of polypropylene (PP) orpolyester fiber (PET).It is an ecological synthetic material with high-strength anti-ultraviolet, freeze-thaw resistance,
corrosion resistance, acid and alkali resistance. It is a new high-tech special material, which can reach more than 50 years
without degradation and truly achieve zero pollution.
Made by polyester (PET) or polypropylene (PP) fiber as the raw material, making double sides ironed and pressed needle-punched non-woven geotextile through the spun bonded technology, and then processed to bag with specified dimension, fill soil, sand and fertilizer etc. Padding into bag according to local soil conditions and scientific proportion, and then spray seeds which are suitable for local climate, form a new product which could restore or create a new ecosystem
Property:
1. For ecological restoration, infrastructure construction, landscaping and residence;
2. Anti-ultraviolet, anti-humidity, strong corrosion resistance, long service life;
3. In slope engineering, it can replace stone, cement and other materials, can reducing project cost greatly.
4. With the filtration function of permeable cloth, it has a strong protective and stabilizing effect on soil loss
Application
1: Ecological restoration and environment protection
A. On both sides of the river: Natural shore zone environment for both human and wildlife ;
B. Openpit mine recovery: Comprehensive utilization of mine waste rock, scientific regulation settlement area, greening barren hills, purify water, create a mine ecological restoration, barren hills become green new era.
C. The sea shores of the lake shore, Surface of the landslide, Culvert mouth, drainage ditch, soil erosion, irrigation system, Steep slope stability and so on .
2: Infrastructure and clean energy
A. Bridgehead, , railway, highway, dam slope protection
B. The noise protection wall
3: Commercial housing and the harmonious area
A. The roof garden greening, vertical greening, landscape art and so on .
B. Military facilities and flood control emergency, blindage, flood control dam.
C.Constructed wetlands
Geosynthetic Fabric Features
| Product | Capacity | Thickness | Tensile strength | Elongation at break |
| Ecological bag | 50-60kg soil material | 80-120 silk | ≥4.5kn/m | ≥10 ％ |
| ≥4.0kn/m | ≥15％ |
| Nominal fracture strength (KN/m) |
3 |
5 |
8 |
10 |
15 |
20 |
25 |
30 |
40 |
|
| Fracture strength (VERTICAL and vertical) (KN/m) |
3.0 |
5.0 |
8.0 |
10.0 |
15.0 |
20.0 |
25.0 |
30.0 |
40.0 |
|
| Nominal breaking strength corresponds to elongation (%) | 20~100 | |||||||||
| CBR top breaking strength (KN≥) | 0.6 | 1.0 | 1.4 | 1.8 | 2.5 | 3.2 | 4.0 | 5.5 | 7.0 | |
| Mass deviation rate per unit area (%) | ±5 | |||||||||
| Equivalent aperture 0x0(0S) (mm) | 0.07～0.20 | |||||||||
| Vertical permeability coefficient (cm/s) | KX(10-1～10-3), where K=1.0～9.9 | |||||||||
| Tearing strength (vertical and horizontal) (KN≥) | 0.10 | 0.15 | 0.20 | 0.25 | 0.40 | 0.50 | 0.65 | 0.80 | 1.0 | |
Geosynthetic Fabric Geotextile Package
packed as rolls with tight belt and woven bags. It can gurantee convenient unloading and protecting product.
