Landscape Plastic Hdpe Geocell Cellweb Root Protection System

Basic Information
Place of Origin: Luan, China
Brand Name: Wanshengli
Certification: GB, ISO, SGS, ASTM
Model Number: 150mm,200mm
Minimum Order Quantity: 1000sqm
Price: 0.3 USD ~5 USD per sqm
Packaging Details: Standard packing
Delivery Time: 5~8 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram or through alibaba trade assurance
Supply Ability: 30000 sqm per day
Detail Information
Main Material: HDPE Material Product Color: Black
Sample: Support Tensile Yield Strength: 3.75N/mm-29N/mm
Standard: ISO9001,GM-13, ASTM Function: Protect, Strengthen
High Light:

Landscape HDPE Geocell

,

Root Protection HDPE Geocell

,

Hdpe cellweb root protection system


Product Description

Plastic Hdpe Geocell With Confinement System For Landscape Design



Quick Detail:



material: Plastic, PP, High-density polyethylene

height: 150mm, 200mm

function: protection, reinforcement

application: landscape, slope protection



Description



Wanshengli brand geocell is three dimensional, honeycomb like structures produced from high density polyethylene and jointly welded by ultrasonic technique. It's flexible to fold during the transport and installation on construction site. The geocell nets will be filled with soils, granular, cements or other onsite in-fill materials when stretched into web structures, which has powerful and rigid confinement in the lateral and vertical sides.



Our Product is flexible and with high strength three-dimensional materials in the form of polymer plastic sheets firmly bonded together (ultrasonic welding). These sheets form cells of equal size arranged in a special order. When folded, the material has the form of compact module, easy to store and transport. When extended, the material transforms into correctly sized three dimensional cellular structure.





Features:

  • 1. It is capable of expansion and contraction, and it can be folded during transportation and stretched during construction. It constitutes a strong lateral restraint and stiffness structure by filling with materials such as sandstone or concrete.
  • 2. It is formed by light material with stable chemical properties which is resistant to abrasion, photooxidation, acid, and alkali, It is suitable for different soil and desert conditions.
  • 3. It has a higher lateral limit, anti-skid, and anti-deformation, and can effectively enhance the bearing capacity of the roadbed    and load distribution.
  • 4. It can meet different engineering needs by changing height, welding distance, and other geometric dimensiones.
  • 5. It is convenient to connect and can improve construction speed.







Landscape Plastic Hdpe Geocell Cellweb Root Protection System 0



Product Parameter



Product type Height(mm) Welding Distance(mm) Thickness(mm) Tensile Strength Of Welding Points(N/cm) Tensile Strength of Connection of Cell( N/cm) Tensile Strength at Yield of Each Sheet(Mpa)
Smooth and not perforated 50≦H≦250 330≦A≦1000 1.0--1.4 ≧100 ≧120 ≧20
Smooth and perforated 50≦H≦250 330≦A≦1000 1.0--1.4 ≧100 ≧120 ≧20
Textured and not perforated 50≦H≦250 330≦A≦1000 1.0--1.7 ≧100 ≧120 ≧20
Textured and perforated 50≦H≦250 330≦A≦1000 1.0--1.7 ≧100 ≧120 ≧20



Application:

  • To stable the roadbed of railway.
  • To stable the roadbed of highroad.
  • To bear the load of retaining wall.
  • To improvement the shallow riverway.
  • To support the pipeline and sewer.
  • To prevent the landslide by using geocell as a heavy-duty hybrid force retaining wall.
  • To be used as independent wall,wharf and breakwater,etc.
  • For the desert,beaches and the riverbed,the river banks's regulation.
  •

Landscape Plastic Hdpe Geocell Cellweb Root Protection System 1Landscape Plastic Hdpe Geocell Cellweb Root Protection System 2Landscape Plastic Hdpe Geocell Cellweb Root Protection System 3Landscape Plastic Hdpe Geocell Cellweb Root Protection System 4

Landscape Plastic Hdpe Geocell Cellweb Root Protection System 5Landscape Plastic Hdpe Geocell Cellweb Root Protection System 6Landscape Plastic Hdpe Geocell Cellweb Root Protection System 7Landscape Plastic Hdpe Geocell Cellweb Root Protection System 8

Landscape Plastic Hdpe Geocell Cellweb Root Protection System 9Landscape Plastic Hdpe Geocell Cellweb Root Protection System 10Landscape Plastic Hdpe Geocell Cellweb Root Protection System 11Landscape Plastic Hdpe Geocell Cellweb Root Protection System 12
